Balluff IO-Link Betriebsanleitung Seite 38

BAE IO-Link Sensor Amplifier
Main menu Submenu
(1st level) (2nd level)
c
d
e
6 [ ]
g
h
i
j
k
7 E nd
18 english
Parame- Function
ter
E t t Setting external triggers
oF F Teach line inactive
Teach line active:
• SP1 (teach in switch-on point): briefly connect the
t E A
• SP2 (teach in switch-off point): briefly connect the
Applies for switching modes Std, 2Pt, and Win.
E.g. fill level regulation with 2 sensors and amplifiers.
PuMP System 1 reports minimum fill level to system 2 via
control line.
don Setting the switch-on delay
Switch-on delay input (0 – 6500 × 10 ms)
dof Setting the switch-off delay
Switch-off delay input (0 – 6500 × 10 ms)
di SP Submenu: Display settings
F W Display of software version
HW Display of hardware version
L uM Adjusting the luminosity
50 Luminosity approx 50%
100 Luminosity 100%
180 Display text rotation (0/180°)
0 Display not rotated.
180 Display rotated 180°.
VaL Dampening rate display in RUN mode
Off No display of dampening in digits in RUN mode
On Display of dampening in digits in RUN mode
Closing the menu
teach line (white) to U + (brown)
B
teach line (white) to U – (blue)
B
Section
6.6.2
6.6.3
6.6.4
6.7
6.7.1
6.7.1
6.7.2
6.7.3
6.7.4
6.8
