BAE IO-Link Sensor Amplifier
10

Appendix

10.1

Menu structure

Main menu Submenu
(1st level) (2nd level)
1 i n
2 t S
3 SP 1
4 SP2
5 [ ] c onf
a out
b Mod
www.balluff.com
Parame- Function
ter
Analog sensor value (in digits)
Teaching in switchpoints
SP 1 Teach in switchpoint 1
SP2 Teach in switchpoint 2
Manually adjusting switchpoint 1
Manually adjusting switchpoint 2
Submenu: Configuration
Adjusting the switching power amplifier type
P no PNP N.O.
n no NPN N.O.
PP no Push-pull, actuated = high side
P nc PNP N.C.
n nc NPN N.C.
PP nc Push-pull, actuated = low side
Adjusting the switching mode
St d Standard switching mode
2Pt 2-point switching
Wi n Window function
dyn Dynamic operation
After selecting the switching mode: return to the main menu
adjust switchpoints.
Section
6.2
6.3
6.4
6.5
6.6
6.6.1
6.6.1
tS
to
english 17
