BAE IO-Link Sensor Amplifier
Index Name
40 Process Data
Input
60 Setpoints BDC1
• Set-Point
SP1
• Set-Point
SP2
61 Switch Point
BDC1
• Logic
• Mode
70 SIO Output
Type
71 Debounce
• Delay On
• Delay Off
72 External Trigger
73 Display Settings
• Intensity
• Rotation
14 english
Sub- Data
index type
UINT16 R
1 UINT16 R/W
2 UINT16 R/W
R/W
1 UINT8 R/W
2 UINT8 R/W
UINT8 R/W
1 UINT16 R/W
2 UINT16 R/W
UINT8 R/W
Record
1 UINT8 R/W
2 UINT8 R/W
Value range
0...4095
0...4095
0 = normal function
1 = inverted
1 = standard switching
function
2 = 2-point switching
3 = window function
4 = dynamic operation
1 = PNP N.O.
2 = PNP N.C.
3 = NPN N.O.
4 = NPN N.C.
5 = push-pull N.O.
6 = push-pull N.C
0..6500
0..6500
0 = inactive
1 = teach line active
2 = fill level regulation
0 = 50 %
1 = 100 %
0 = normal alignment
1 = rotated by 180°
Comment
Current process data, see
section 7.2
Switchpoint 1, see
section 6.4
Switchpoint 2, see
section 6.5
BDC1 configuration
Switching logic
Switching mode, see
section 6.6.1.
Switching power amplifier
See sections 6.6.3 and
6.6.4
Switch-on delay x
10 msec
Switch-off delay x
10 msec
See section 6.6.2.
If bit 3 Local
Parametrization in the
Device Access Lock
parameter is set, the
External Trigger input is
active.
See section 6.7.
