BAE IO-Link Sensor Amplifier
6.6.4 Setting the switch-off delay
doF
►
Set a value for the switch-off delay (value
range: 0 – 6500 x 10 ms).
>> >> Switch-off is delayed by the set value.
6.7

Display settings

di SP
6.7.1 Display of software/hardware
version
Display Configuration
Firmware version (e.g. FW0214)
FW
Hardware version (e.g. HW0215)
HW
6.7.2 Adjusting the luminosity
Display Configuration
Luminosity at 50%
50
Luminosity at 100%
100
6.7.3 Display text rotation (0/180°)
Display Configuration
Text rotated 0°
0
Text rotated 180°
180
6.7.4 Dampening rate display in RUN
mode
Display Konfiguration
No display of dampening in digits in
Off
RUN mode
Display of dampening in digits in
On
RUN mode
www.balluff.com
6.8

Closing the menu

E nd
►
Press the button.
>> >> All settings are saved; the display
run
indicates and the sensor
dampening rate in digits.
6.9

Returning to factory settings

►
Briefly press the
simultaneously.
>> >> After releasing the buttons,
appears on the display.
english
and buttons
r St
11
