BAE IO-Link Sensor Amplifier
6.2

Analog sensor value (in digits)

i n
Indicates a value dependent on the sensor,
distance (relative measurement), or dampening.
Display range: 0 – 4095
6.3

Teaching in switchpoints

t S
NOTe
The output functions SP1 and SP2 are
dependent on the selected switching mode
and the selected output configuration
section 6.6.1).
SP 1
►
Teach in switchpoint 1 and store as SP1.
SP2
►
Teach in switchpoint 2 and store as SP2.
6.4 Manually adjusting switchpoint 1
SP 1
►
Adjust the value (0 – 4095) using the
buttons.
>> >> The adjustment is effective immediately.
6.5 Manually adjusting switchpoint 2
SP2
►
Adjust the value (0 – 4095) using the
buttons.
>> >> The adjustment is effective immediately.
6.6

Configuration

[ ]c onf
NOTe
The configured settings are effective
immediately.
The high teach value is assigned to SP1:
• higher dampening
• smaller object distance
The low teach value is assigned to SP2:
• smaller dampening
• larger object distance
8 english
6.6.1
out
Display
P no
n no
PP no
P nc
Mod
n nc
out
(see
PP nc
Adjusting the switching mode
Mod
NOTe
After the switching mode is selected, the
selection for adjusting the switchpoints returns
to the main menu
or
For examples of typical teach-in processes, see
the figures in section 6.
Standard switching mode
St d
The system generally works with only one defined
or
switchpoint: object or fill level (half of active
surface covered with medium) reliably detected.
If the measurement falls below the switchpoint by
a small amount, the output switches to off.
Output
On
Off
Adjusting the switching power
amplifier type
Configuration
PNP N.O.
NPN N.O.
Push-pull, actuated = high side
PNP N.C.
NPN N.C.
Push-pull, actuated = low side
t S
.
tS: SP2 tS: SP1
SP1
Sensor value
