6. In Windows Explorer, navigate to the computer drive for the USB
memory stick.
7. Right click the DATA.tsv file (or the secure .xls file if enabled in the
Communications Setup screen) and select Open with > Excel. When
the file is open, move the data to the computer.
Note: Each time data are saved to the USB memory stick, the DATA file on the
memory stick is overwritten.

Save data with an Ethernet connection

Note: This option is available only when the instrument is used with a charge
cradle. The cradle is an optional item for some instrument models
on page 5).
1. Connect the Ethernet cable and power cable to the instrument base.
2. Navigate to the Communication Setup menu and push the Select
button.
3. In the Communication Setup screen, set the IP address, Subnet
Mask, and Gateway address. To do this, do one of the following:
a. Put the IP Address, Subnet and Gateway data in the appropriate
fields OR
b. Select the DHCP check box.
If the DHCP box is selected, the IP Address, Subnet Mask and
Gateway are set automatically when the instrument is connected
to the network. The instrument will ask for an IP address if:
• the instrument is put in an Ethernet connected cradle.
• the instrument is in a cradle and a power cycle is done.
• the user exits from the communications screen after changes
were made but the DHCP box was still checked.
4. Install the instrument in the cradle.
5. Open the Internet browser. In the Address bar, put one of the items
that follow:
a. The IP address from the Communication Setup screen
b. hpc+ the instrument serial number. The serial number is in the
instrument Diagnostic screen.
Example: hpc123456789
The HPC Data Web Server page opens.
14 English
Note: For this option, the PC and the HHPC+ instrument must be
connected to the same local area network. The PC and the HHPC+
instrument must not be separated by a router, and the network must be
configured to allow packet broadcasting. In case of difficulty, contact your
network administrator.
c. Press the "rebuild button" on the browser page to build the file.
6. Open the DATA.tsv file or if enabled the secure DATA .XLS file.
Move data to a mass storage device
1. Connect the mini-USB cable to the mini-USB port on the instrument
(HHPC models
and the USB port on the PC.
2. In Windows Explorer on the PC, navigate to the HPC USB drive and
open the DATA.TSV file.
3. Disconnect the USB cable or do a power cycle of the instrument.
New data is added to the DATA file.
Update instrument firmware
1. Put the update file on a USB memory stick.
2. Attach the memory stick to the USB port on the bottom of the
instrument.
3. Push and hold down the menu key and push the power key.
The instrument scans the USB drive for updates and installs the
update.

Maintenance

Multiple hazards. Do not disassemble the instrument for maintenance or service.
If the internal components must be cleaned or repaired, contact the
manufacturer.
Personal injury hazard. Only qualified personnel should conduct the tasks
described in this section of the manual.
W A R N I N G
C A U T I O N
