SATAjet 5000 B RP/HVLP PHASER Operating Instructions
Content [Original Version: German]
1. Symbols ................................ 435
2. Technical Data ...................... 435
3. Scope of Delivery ................. 436
4. Design of the Spray Gun ...... 437
5. Intended Use ........................ 437
6. Safety Instructions ................ 437
7. Use ....................................... 440
1.

Symbols

Danger! Risk which will cause heavy injuries or death.
Notice! Risk which could cause damage.
Explosion risk! Warning against risk which could cause
heavy injuries or death.
Information! Useful tips and recommendations
2.

Technical Data

Gun inlet pressure
RP Operating range
(Field of application)
Compliant
HVLP Operating range
(Field of application)
HVLP
Compliant
Compliant legislation
Lombardy/Italy
8. Cleaning the Spray Gun ....... 442
9. Maintenance ......................... 443
10. Troubleshooting .................... 446
11. Disposal ................................ 447
12. After Sale Service ................. 448
13. Warranty / Liability ................ 448
14. Spare Parts .......................... 448
16. EC Declaration of
Conformity ............................ 449
7 psi - 35 psi
max. 29 psi
7 psi - 35 psi
max. 29 psi
> 29 psi (air cap pressure > 10 psi)
< 35 psi (air cap pressure < 15 psi)
US
435
