6 Technical Data

Audio input impedance:
Audio input level:
Audio output impedance:
Audio output level:
Audio processing:
ROM:
RAM:
Operating temperature:
Front panel:
Rear panel:
Power Supply:
Dimensions:
Weight:
47 kΩ
10 mVp-p... 2Vp-p
1 kΩ
Max. 3 Vp-p (open circuit), adjustable in 1 mV steps
Digital signal processor DSP56303 clocked at 100 MHz
Max. 256 kByte, CMOS, FLASH-ROM for easy updates
Static: 256k words (24 bit) DSP RAM
-10 to +50 °C
Labelled
A total of 5 LED´s split into various functional groups
DIP-Switch for basic configurations
Labelled
Input for power supply
Socket for connection to the transceiver
Socket for Transceiver power switching relay
GPS-connector as 3 wire screw terminal
USB connector (optically isolated and USB-powered)
+10 to +20 V DC, 120 mA max. Reverse polarity protected
Fuse selfresetting
Width 82 x Height 22 x Depth 102 mm
107 g
