SCS Tracker Installationsanleitung Seite 29

The TS-50 can only be connected via the microphone jack:
The TS-480 has a 6 pin Mini-DIN connector:
Signal
GND
PTT
AF-OUT
AF-IN
This cable is available completely assembled.
Refer to chapter 5 on page 28.
3.3.3 Connection DSP TNC – YAESU (HF)
Some YAESU transceivers use a 5 pin DIN plug (Packet) and can be connected this way:
Signal
GND
PTT
AF-OUT
AF-IN
Smaller YAESU's use a 6 pin Mini-DIN connector, whereby with multiband transceivers two
different connection schemes must be destinguished:
- For HF and 1k2 Packet-Radio:
Signal
GND
PTT
AF-OUT
AF-IN
This cable is available completely assembled.
Refer to chapter 5 on page 28.
Signal TNC
GND PIN 2
PTT PIN 3
AF-OUT PIN 1
AF-IN PIN 4
Table 6: KENWOOD TS-50
TNC
PIN 2
PIN 3
PIN 1
PIN 4
Table 7: KENWOOD 6 pin Mini-DIN
TNC
PIN 2
PIN 3
PIN 1
PIN 4
Table 8: YAESU 5 pin
TNC
PIN 2
PIN 3
PIN 1
PIN 4
Table 9: YAESU 6 pin Mini-DIN
Color Kenwood
white PIN 7, 8
yellow PIN 2
violet PIN 1
green PIN 6
Color YAESU
white PIN 2
yellow PIN 3
violet PIN 1
green PIN 5
Color YEASU
white PIN 2
yellow PIN 3
violet PIN 1
green PIN 4
Color YAESU
white PIN 2
yellow PIN 3
violet PIN 1
green PIN 5
3. Installation
23
