3. Installation
3.3.1 Connection DSP TNC – ICOM (HF)
Most ICOM transceivers that use 8 pin DIN plug (ACC) can be connected this way:
The smaller ICOM transceivers (e.g. IC-706) often use a 13 pin DIN plug for ACC:
3.3.2 Connection DSP TNC – Kenwood (HF)
Most Kenwood transceivers that use 13 pin DIN plug (ACC2) can be connected this way:
Signal
GND
PTT
AF-OUT
AF-IN
This cable is available completely assembled.
Refer to chapter 5 on page 28.
22
Signal TNC
GND PIN 2
PTT PIN 3
AF-OUT PIN 1
AF-IN PIN 4
POWER PIN 5
This cable is available completely assembled.
Refer to chapter 5 on page 28.
Table 3: ICOM 8 pin
Signal TNC
GND PIN 2
PTT PIN 3
AF-OUT PIN 1
AF-IN PIN 4
POWER PIN 5
This cable is available completely assembled.
Refer to chapter 5 on page 28.
Table 4: ICOM 13 pin
TNC
PIN 2
PIN 3
PIN 1
PIN 4
Table 5: KENWOOD
Color ICOM 8 pin
white PIN 2
yellow PIN 3
violet PIN 4
green PIN 5
blue PIN 7
Color ICOM 13 pin
white PIN 2
yellow PIN 3
violet PIN 11
green PIN 12
blue PIN 8
Color Kenwood
white PIN 4, 8, 12
yellow PIN 9
violet PIN 11
green PIN 3
