6 Technical Data

Audio input impedance:
Audio input level:
Audio output impedance:
Audio output level:
Audio processing:
Central processor:
ROM:
RAM:
System monitoring:
Operating temperature:
Front panel:
Rear panel:
Power Supply:
Dimensions:
Weight:
47 k
10 mVp-p... 2Vp-p
1 k
Max. 3 Vp-p (open circuit), adjustable in 1 mV steps
Digital signal processor DSP56303 clocked at 100 MHz
768 kByte additional DSP-RAM for data and program
Motorola MC68360 QUICC 32 bit CMOS CPU clocked at 25 MHz
Max. 256 kByte, CMOS, FLASH-ROM for easy updates
Static: 2 MByte, CMOS
With an internal processor watchdog
-10 to +50 °C
Labelled
A total of 8 LED´s splitted into various functional groups
ON / OFF Touch sensor switch
Labelled
Input for power supply
Socket for connection to the transceiver
Socket for transceiver remote control connections
GPS-connector as 3 wire screw terminal
USB connector
+10 to +20 V DC, 300 mA max. Reverse polarity protected
Fuse selfresetting
Width 125 x Height 43 x Depth 138 mm
450 g
