5. Accessories
5 Accessories
For the SCS Tracker / DSP TNC the following accessories are available:
•
Adapter 6 pin miniDIN male plug to 8 pin DIN socket
This adapter is always necessary to use one of the cabes below! It adapts the miniDIN
connector of the SCS Tracker / DSP TNC to the standard "PTC"-series 8 pin DIN socket.
Order-No.: 8180
•
Packet-Radio 9k6 cable
Direct connection from VHF/UHF-transceivers with DATA-connector (6 pin Mini-DIN)
to the PTC (5 pin DIN). Adapter 8180 required!
Order-No.: 8050
•
ICOM 8 pin cable
ICOM audio cable, PTC 8 pin DIN to ICOM 8 pin DIN (e.g. for M710, IC-735, IC765,
IC-M802 and more). Adapter 8180 required!
Order-No.: 8090
•
ICOM 13 pin cable
ICOM audio cable, PTC 8 pin DIN to ICOM 13 pin DIN (e.g. for M706, IC-718). Adapter
8180 required!
Order-No.: 8110
•
YAESU Audio cable
PTC 5 pin DIN to YAESU FT-817 6 pin Mini-DIN (e.g. for FT-100, FT-817, FT-897).
Also usable for 1k2 Packet-Radio. Adapter 8180 required!
Order-No.: 8120
•
KENWOOD Audio cable
PTC 8 pin DIN to KENWOOD ACC2 13 pin DIN. Adapter 8180 required!
Order-No.: 8160
•
2 m Audio extention cable
8 pin DIN socket to 8 pin DIN connector. Adapter 8180 required!
Order-No.: 8140
•
3 m Audio extention cable
8 pin DIN socket to 8 pin DIN connector. Adapter 8180 required!
Order-No.: 8150
Shielded cables with molded connectors on one side, tinned open ends on the other side
(pigtail), 1,5 meter.
• Cable with 6 pin miniDIN connector
Order-No.: 8015
For additional accessories and prices please refer to our homapage
call for a recent pricelist.
28
http://www.scs-ptc.com or
