Installation

Please detach the illustrated centre pages
before reading the installation instructions.
You can now read the text in conjunction
with the illustrations.
Install the appliance in a dry, well
ventilated room. But not in direct sunlight
and not near a heat source, e.g. cooker,
radiator, etc. If installation near a heat
source is unavoidable, use a suitable
insulating plate or observe the following
minimum distances to a heat source:
3 cm to an electric cooker.
30 cm to an oil or solid fuel cooker.
Appliances with fitted handles must be
situated at least 55 mm from the wall on
the hinge side so that the door can be
opened by 90°. Fig. 3
16

Aligning the appliance

Fig. 4
The appliance must be level. If the floor is
uneven, use the front height adjustable
feet.
Changing over the
door hinges
(If required)
Fig. 0
Installation in numerical sequence.
Changing over
the door handles
Fig. 5

Your new appliance

Fig. 1
1 Temperature selector
2 Freezer compartment flap*
3 Freezer shelf
4 Large freezer drawer
5 Freezer drawer
6 Door compartment for ice blocks
7 Height adjustable feet
*not all models
