Commissioning - Lukas AM 07/100 GH Bedienungsanleitung

Vibration acelleration:
Drive:
Accessories included:
- 1 allen key Ø 6mm
Optional Equipment:

3. Commissioning

The power tool must only be connected to the compressed air network using a
pressure reducer (combination of water separator – pressure control valve –
lubricator). The nominal diameter of the pressure reducer must comply at least with
the hose diameter specified in the technical data. The pressure control valve must be
set to the value of 0.63 MPa.
The pressure reducer must be installed at the working height of the power tool or
above.
The compressed air hose supplied with the machine must be directly connected to
the pressure reducer and must not be lengthened.
The lubricator must be adjusted so as to supply approx. 3 drips per minute at a
pressure of 0,63 MPa. Only oil types quoted in the table below may be used.
In the case of a prolonged period without use (e.g. overnight), the machine must be
disconnected from the compressed air system.
Stand: 27.10.2008
2
< 2,5 m/s
Vane Air Motor
13 - AM 07/100 GH -
