Temperature-Block - ECOLAB lmit 09 Kurz- Betriebsanleitung

REF_TEMP:
CIP1_TEMP_COEFF:
CIP1_PROD_NO:
CIP1_RANGE_SEL:
CIP1_SEN_TYPE:
CIP2_TEMP_COEFF:
CIP3_TEMP_COEFF:
CIP4_TEMP_COEFF:
CIP2_PROD_NO:
CIP3_PROD_NO:
CIP4_PROD_NO:
CIP2_RANGE_SEL:
CIP3_RANGE_SEL:
CIP4_RANGE_SEL:
CIP2_SEN_TYPE:
CIP3_SEN_TYPE:
CIP4_SEN_TYPE:
5.4

Temperature-Block

Relative Index
10
OUT:
Value:
Status:
417101561_LMIT09_DPV1
The reference-temperature of the conductivity measurement:
Code
0
1
2
The temperature coefficient of conductivity measurement in the
CIP range. (Numeric value between 0,00 % and 5,00 %
The product number for the CIP-range (code see chapter 5.8)
The selection between manual measurement range setting at
low conductivity values and automatic range setting
Code
0
1
Selection of measurement mode:
Code
0
1
see CIP1_TEMPC_OEFF
see CIP1_PROD_NO
see CIP1_RANGE_SEL
see CIP1_SEN_TYPE
Name Data type Bytes
OUT Record
The Temperature value and its Status:
Byte 1-4
Measured value
Temperature value supplied by
The status value supplied by LMIT09:
Code Status
0 No fault, unit works properly
1 Configuration fault
3 Temperature coefficient and dT fault
4 Cond. sensor fault general
5 Temperature sensor breakdown
6 Overflow of conductivity measurement ampflifier (> 2,5 S/cm)
7 Communication fault at
16 Conductivity/Concentration-value Overflow (> 5 weith %)
128 + x Measurement value frozen
Where x is the number, added from one of the above status codes.
- 21 -
Meaning
0°C
20°C
25°C
Meaning
Automatic measurement range switch over
Manual measurement range switch over @ 0 - 200µS
Meaning
Concentration measurement
Conductivity measurement
Access Value Range
5 ac_r,c_r
5
Status
LMIT09
LMIT09 between Display- & motherboard
Initial Value
-
in IEEE-Float-Format
Rev. 03-10.12
