Equipment-Block - ECOLAB lmit 09 Kurz- Betriebsanleitung

5.3

Equipment-Block

Relative Index
8
9
11
12
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
*ac_r = acyclic read; ac_w = acyclic write
SOFTWARE_REVISION:
HARDWARE_REVISION:
DEVICE_MAN_ID:
DEVICE_SER_NUM:
CIP_SELECT:
Code Meaning
Configuration of CIP-Range 1
0
(cyclic values of this range are frozen during write, configuration parameter of the CIP range can be written).
Configuration of CIP-Range 2
1
(cyclic values of this range are frozen during write, configuration parameter of the CIP range can be written).
Configuration of CIP-Range 3
2
(cyclic values of this range are frozen during write, configuration parameter of the CIP range can be written).
Configuration of CIP-Range 4
3
(cyclic values of this range are frozen during write, configuration parameter of the CIP range can be written).
128 Confirm of configuration parameter
The procedure of a CIP configuration is described in the example below.
LANGUAGE:
417101561_LMIT09_DPV1
Name
SOFTWARE_REVISION
HARDWARE_REVISION
DEVICE_ID
DEVICE_SER_NUM
CIP_SELECT
LANGUAGE
REF_TEMP
CIP1_TEMP_COEFF
CIP1_PROD_NO
CIP1_RANGE_SEL
CIP1_SEN_TYPE
CIP2_TEMP_COEFF
CIP2_PROD_NO
CIP2_RANGE_SEL
CIP2_SEN_TYPE
CIP3_TEMP_COEFF
CIP3_PROD_NO
CIP3_RANGE_SEL
CIP3_SEN_TYPE
CIP4_TEMP_COEFF
CIP4_PROD_NO
CIP4_RANGE_SEL
CIP4_SEN_TYPE
The actual Software revision code.
The actual hardware revision code.
Manufacturer specific unit description.
Unit number, from main setting
By writing to this parameter the CIP range can be switched over.
Fig. 5.1
The language for display indication on LMIT09.
Code
0
1
2
3
- 20 -
Data type Bytes Access
VisibleString 3 ac_r
VisibleString 11 ac_r
VisibleString 12 ac_r
VisbleString 6 ac_r
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
In the example the
CIP range 2 as concentration measurement
unit for NaOH
Meaning
German
English
French
Spanish
Value Range Initial Value
"2.3"
"3.892.56-01"
"LMIT09 DP/V1"
"000000"
128
LMIT09 is programmed in
Rev. 03-10.12
0
0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
