2.3 FIXTURE MODE „Extended"
The A8 offers 5/3 different channel options. With PERSONALITY -> FIXTURE MODE (selection between Standard
or Extension mode) and with DMX MODE (selection of S8, S16, C8, C16 and E8 respectively M1, M2, M3) you can
select the different channel options. The selected mode will be displayed in the main menu.
Mode 1 (M1)
Channel 1
Pan
Channel 2
Pan ne
Channel 3
Tilt
Channel 4
Tilt ne
Channel 5
Control
Channel 6
Shutter
Channel 7
Dimmer
Channel 8
Zoom
Channel 9
Mapping
Channel 10
Pattern mode
Channel 11
Pattern
Channel 12
Pattern speed
Channel 13
White spread
Channel 14
Sparkle
Channel 15
Sparkle speed
Channel 16
CTC
Channel 17
Fixed Colors
Channel 18
PAN/Tilt speed
Channel 19
Effect speed
Channel 20
Segment shutter / blackout
move
Channel 21
Red
Channel 22
Green
Channel 23
Blue
Channel 24
White
Channel 25
Red
Channel 26
Green
Channel 27
Blue
Channel 28
White
Channel 29
Red
Channel 30
Green
Channel 31
Blue
Channel 32
White
Channel 33
Channel 34
Channel 35
Channel 36
Channel 37
Channel 38
Channel 39
Channel 40
Channel 41
Channel 42
Channel 43
Channel 44
- 30 -
}
Glow
}
Main
}
Pattern
Mode 2 (M2)
Pan
Pan ne
Tilt
Tilt ne
Control
Shutter
Dimmer
Zoom
Mapping
Pattern mode
Pattern
Pattern speed
White spread
Sparkle
Sparkle speed
CTC
Fixed Colors
PAN/Tilt speed
Effekt speed
Segment shutter / blackout
}
move
Red
Red ne
Green
Green ne
Glow
Blue
Blue ne
White
}
White ne
Red
Red ne
Green
Green ne
Main
Blue
Blue ne
White
}
White ne
Red
Red ne
Green
Green ne
Pattern
Blue
Blue ne
White
White ne
Mode 3 (M3)
Pan
Pan ne
Tilt
Tilt ne
Control
Shutter
Dimmer
Zoom
Mapping
Pattern mode
Pattern
Pattern speed
White spread
Sparkle
Sparkle speed
CTC
Fixed Colors
PAN/Tilt speed
Effekt speed
Segment shutter / blackout
move
Red
Green
Blue
White
