Problem
No or low supply quan-
tity, interrupted or spit-
ting spraying jet
Material escapes from
the material tip after
having released the
trigger
Poor spray pattern
Material outlet in
packing nut
Needle does not return
to position until the trig-
ger has been release or
only returns slowly
Sprayer does not auto-
matically switch off
in the AUTO-START
setting
Cause
No pressure build-up of cup.
Connecting thread between
cup and gun is blocked by dried
paint, not tightly screwed down
or damaged.
Air supply to the cup blocked.
Blocked filter screen.
The needle packets are not
adjusted correctly.
Note: Material loss caused by
the packets impairs material
pressure and causes material
discharge from the gun housing.
Needle not positioned in the
material tip.
Packing nut is too tight.
Air cap horn bore and/or materi-
al tip blocked.
Packing nut is loose
Packing nut is too tight
Leaks on air hose connections.
Air leak on the gun
Action
Check the cup system for leaks. See "Cup system" secti-
on
Clean connecting thread and filter screen (if applicable).
Check whether the gun air hose and the connection
pieces are blocked, bent or leaking, replace as required.
Replace the filter screen if it is blocked or remove it if
the material is very viscous.
Clean the gun body. Adjust the needle seal.
Check whether the material tip is loose or whether
the tip or needle have been deformed; tighten the tip
or replace the corresponding parts, as required. Check
whether the tip/needle combination is correct.
Slowly loosen the packing nut until the needle can return
to its position unhindered.
Soak air cap and/or material tip in solvent. Only clean the
air cap holes using non-metal objects in order to prevent
damage
Lightly tighten packing nut and check again. Repeat until
the packing is completely sealed.
Slowly loosen the packing nut until the needle can return
to its position unhindered.
Only use original house and gun.
Disconnect air hoses. Check that the O-ring is in place
in the connection piece on the turbine at the hose end.
When using a whip end, check that the seal is in place in
the connection piece. Securely fit all hose connections.
If Auto-Start works and the air valve at the hose end is
closed, clean the gun. See clean the gun.
Check that the material valve is closed. See detailed
drawing of the gun.
Replace the material valve O-ring. See detailed drawing
of the gun.
Replace the air valve. See detailed drawing.
87 Original instruction
