Device elements

1 Nameplate
2 Holder for crevice nozzle
3 Holder for suction pipes
4 Power cord
5 Drain hose
6 Suction hose
7 Suction head lock
8 Socket
9 Impeller
10 Chassis
11 Dirt receptacle
12 Steering roller
13 Chassis handle
14 Suction support
15 Floor nozzle
16 Suction pipe
17 Main switch
18 Suction head
19 Carrying handle
20 Cable hook
21 Bender
22 Cartridge filter
23 Fastening nut
24 Float
Start up
Dry vacuum cleaning
Caution
For dry vacuuming, the cartridge filter must
always be installed.
When vacuuming fine dust, you may
–
also use an additional paper filter bag or
a membrane filter (special accessory).
Inserting the paper filter bag
Illustration
Illustration
Release and remove the suction head.
Insert the paper filter bag or the mem-
brane filter (special attachment).
Insert and lock the suction head.
Wet vacuum cleaning
Inserting the rubber lips
Illustration
Remove the brush strips.
Install the rubber lips.
Note: The structured side of the rubber lips
must point outwards.
Remove the paper filter bag
If the appliance is used to vacuum wet dirt
–
the paper filter bag or the membrane filter
(special accessory) must always be re-
moved.
Installing an additional filter
Release and remove the suction head.
Turn the suction basket by 180° and
keep it aside.
Loosen the mounting nuts
Remove the cartridge filter.
Illustration
Insert the fastening nut and tighten it.
Install the additional filter.
Insert and lock the suction head.
Clip connection
Illustration
The suction hose is equipped with a clip
system. All C-35/C-DN-35 accessories can
be connected.
Turning on the Appliance
Plug in the main plug.
Switch on the appliance at the main
switch.
Working with electrical power tools
Danger
Risk of injury and damage! The socket out-
let is only for the connection of power tools
to the vacuum cleaner. Any other use of the
socket outlet is not permitted.
Connect the mains plug of the electric
power tool to the vacuum cleaner.
Switch on the appliance at the main
switch.
The vacuum cleaner is now ready. You can
now switch on the electrical power tool.
