Flight operation

The model is now ready for its maiden flight.
Programme the rotational direction of the servos and their travel ranges.
Elevator and ailerons must have a deflection of about 4 - 5 mm on the trailing edges of the
control surface; allow as much deflection as possible for the rudder.
The flight control system is properly detected by most remote control systems in terms of the
endpoints for "motor off" and "full throttle". If the flight control system is not initialized by the
remote control you are using after connecting the flight battery, adjust the travel ranges for the
throttle stick to the maximum values on your transmitter.
With the battery mounted adjust the centre of gravity (spaced approx. 1/3 apart from the lead-
ing edge).
The flight control system can't be programmed.
It features an EMF brake as well as low voltage detection (capacity reduction at ap-
prox. 6.0 V).
Disposal
The product must not be disposed of in household waste!
Dispose of an unserviceable product in accordance with the relevant statutory regula-
tions.

Technical data

Engine
Operating voltage ................................................ 6 - 13 V/DC
Current rating (continuous) .................................. 5.5 A
Current rating (max. 20 s) ................................... 7 A
KV ........................................................................ 2200
Weight ................................................................. approx. 12 g
Flight control system
Operating voltage ................................................ 6.0 - 8.4 V (2S Lipo)
Current rating (continuous) .................................. 6 A
Current rating (max. 10 s) ................................... 8 A
BEC ..................................................................... 5 V/DC, 0.8 A
Weight ................................................................. approx. 5.5 g
Propeller .............................................................. 130 x 79 mm (5.1" x 3.1")
Aileron servo
Operating voltage ................................................ 4.8 - 6.0 V/DC
Propulsive thrust at 4.8 V .................................... 0.70 Ncm
Gear ..................................................................... plastic
Weight ................................................................. approx. 8 g
Elevator and rudder servos
Operating voltage ................................................ 4.8 - 6.0 V/DC
Propulsive thrust at 4.8 V .................................... 0.25 Ncm
Gear ..................................................................... plastic
Weight ................................................................. approx. 3.7 g
