16 | English

Work Examples

Laying of Square Tiles (see figure A)
Position the measuring tool in a corner in such a manner that the 0° laser line
runs parallel to a wall and the T-edge 7 of the measuring tool faces against the
wall. Lay the first square tile in such a manner that any right-angled side of the tile
is seated flush on the 0° and the 90° laser line.
Laying with Diagonal Pattern (see figure B)
Position the measuring tool in such a manner that the 90° scale 6 faces directly
against a wall. Begin with the first diagonal tile at intersecting point P.
Laying from Edges (see figure C)
Position the measuring tool with the L-edge 11 facing against the edge from
which on you want to lay the tiles. The 90° laser line should run parallel to this
edge. The 0° laser line now marks the bottom tile row.
Tile laying in Kitchenettes (see figure D)
Firstly, determine the height at which the first tile row is supposed to begin.
Attach the measuring tool vertically to the wall so that the 90° laser line displays
the bottom edge of the first tile row.

Maintenance and Service

Maintenance and Cleaning

Keep the measuring tool clean at all times.
Do not immerse the measuring tool in water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any cleaning agents or
solvents.
Regularly clean the surfaces at the exit opening of the laser in particular, and pay
attention to any fluff or fibres.
In all correspondence and spare parts orders, please always include the 10-digit
article number given on the type plate of the measuring tool.

After-sales Service and Application Service

Our after-sales service responds to your questions concerning maintenance and
repair of your product as well as spare parts. Exploded views and information on
spare parts can also be found under:
www.bosch-pt.com
Bosch's application service team will gladly answer questions concerning our
products and their accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange the collection of a
product in need of servicing or repair.
Tel. Service: (0844) 7360109
E-Mail: boschservicecentre@bosch.com
1 609 92A 0K3 | (22.10.14) Bosch Power Tools
