2-2. CH03 (Dimensions)

3 2 1
7
10 9 8
(1.33")
Model
Cable length
CH03-01
1 m (39.37")
CH03-03
3 m (118.11")
CH03-05
5 m (196.85")
CH03-10
10 m (393.70")
16
Round connector (female); JAE: JB1HB10SL2 NIHON KOKU DENSHI KOGYO
4
44
(1.73")
10-pin mini- DIN connector (male)
(Hosiden Corporation TCP8938)
33.7
43.7 300
(11.81")
(1.72")
Interpolation box
Thickness
t=21(0.83")
C H 0 3 -
S e r i a l Ｎｏ．
******
MADE IN JAPAN
(101)
(3.98")
Cable length
Unit : mm (in)
