Contents
1. Outline ........................................................................ 12
1-1. Introduction ........................................................ 12
1-2. Parts Configuration ............................................ 13
1-3. System Configuration ......................................... 14
2. Name and Function of Each Part (Dimensions) .... 15
2-1. CH02 (Dimensions) ............................................ 15
2-2. CH03 (Dimensions) ............................................ 16
3. Electrical Adjustment ................................................ 17
〈1〉 Removing the upper case ............................... 17
〈2〉 Board layout .................................................... 18
〈3〉 Mounting the display unit (LT20A) .................. 19
〈4〉 Electrical adjustment ....................................... 19
〈5〉 Mounting the upper case ................................ 22
12

1. Outline

1-1. Introduction

CH02 series cables are used to connect SR118 series
scale units to the LT20A display unit.
CH03 series cables are used to connect SR127/128 series
scale units to the LT20A display unit.
When used in combination with a SR118 series or SR127/
128 series scale unit, electrical adjustment is necessary.
Perform this adjustment according to the procedures
outlined in this manual.
Note
• Be sure to perform the electrical adjustment for the
CH02/03 cable together with the used scale unit.
• If the adjustment is not performed as specified, the scale
accuracy specifications will not be satisfied.
See the SR127/128 or SR118 series Instruction Manual
supplied with the scale unit for the connection method.
