ATTENTION
Risk of damage!
Operating the engine without a filter element or with a
damaged filter element can cause engine damage.
– Never run the engine without the air filter element or
with a damaged filter element. This would allow dirt
into the engine, which would result in severe dam-
age to the engine.
ATTENTION
Fouled air filters diminish the engine output
due to reduced air supply to the carburettor.
Regular inspection is therefore essential.
Note:
The air filter should be checked every 25 operating hours
and cleaned as required. The air filter must be checked
more often in case of very dusty air.
1. Remove the screw (7a) and remove the air filter cover
(7).
2. Check the air filter cover (7) for holes or cracks. Re-
place any damaged insert.
3. Take the air filter (7b) out.
4. Wipe off dirt on the inside of the filter housing with a
clean moist cloth. Make sure that no direct enters the
opening. Set the air filter cover (7) on the filter housing
for the duration of the filter cleaning process.
5. Check the air filter (7b) for damage and replace it if
necessary.
6. Knock the air filter (7b) against a hard surface to re-
move the dirt. Never try to brush the dirt out as this
will press it into the fibres.
7. If necessary, clean the air filter (7b) additionally in
warm water and mild soap solution. Rinse it thorough-
ly with clean water and let it dry well.
8. Reinsert the clean air filter (7b).
9. Put on the air filter cover (7) and secure it with the
screw (7a).

13 Storage and transport

WARNING
Danger of injury and burning!
The product can start unexpectedly and cause injuries.
– Switch off the engine before carrying out any clean-
ing or maintenance work.
– Allow the engine to cool down.
– Disconnect the spark plug connector from the spark
plug.
• Empty the product completely.
• Clean and check the product for damage.
13.1

Preparation for storage

WARNING
Do not remove the fuel in enclosed spaces, near fire or
when smoking. Petrol fumes can cause explosions and
fire.
If the product will not be used for a period of more than 30
days, the following measures must be taken to prepare it
for storage.
1. Clean and check the product for damage.
2. Empty the fuel tank using a petrol extraction pump.
3. Start the engine and let it run until the remaining fuel
is used up.
4. Store fuel in tanks specifically designed for this pur-
pose.
5. Change the oil at the end of every season.
6. Remove the spark plug connector from the spark plug.
7. Pour 1 teaspoon of clean 2-stroke oil into the combus-
tion chamber. Pull the starter rope slowly several
times to coat internal components.
8. Store the product in a well-ventilated place or area.
13.2 Transport
WARNING
Switch off the product and remove the spark
plug connector from the spark plug!
ATTENTION
Danger of burning!
Keep the hot silencer away from your body. There is a
risk of burns!
WARNING
Danger of injury!
Unintended and unexpected start-up of the product may
lead to injuries.
• Switch off the product before any transport, even over
short distances. Secure the product against tipping
over during transport (including in vehicles) to prevent
fuel loss, damage or injury.

14 Repair and ordering spare parts

After repairs or maintenance, make sure that all safety-re-
lated parts are installed and are in perfect condition. All
parts which may cause injury must be kept where they
are inaccessible to children or others.
ATTENTION
According to the German Product Liability Act, no liabili-
ty is accepted for damage caused by improper repairs
or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialists. The same applies to
accessory parts.
www.scheppach.com GB | 31
