The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
3 Product description (Fig. 1-7)
1. Magazine attachment
2. Adjusting wheel
2a. Scale
3. Locking lever
4. Belt retractor
5. Belt guide
6. Sliding shoe
6a. Release button
6b. Trigger
6c. Latching lugs
6d. Detents
6e. Scale
7. Screw stop
8. Release button
9. Screwdriver bit (165 mm)
10. Drywall screws*
* = may not be included in the scope of delivery!
4 Scope of delivery (Fig. 1)
Item Quantity Designation
9. 1 x Screwdriver bit (165 mm)
1. 1 x Collated magazine attachment
1 x Operating manual
5 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
6 Technical data
Screw length
Max. shaft diameter
Max. screw diameter
Screw-in depth
Subject to technical changes!
7 Safety instructions
Keep all safety information and instructions for future
reference!
WARNING
Read all safety warnings, instructions, illus-
trations and specifications provided with this
product.
Failure to observe the following instructions can result
in serious injuries.
WARNING
Before you start working with the product, familiarise
yourself well with all the control parts.
– Practice using the product and have an experienced
user or specialist explain its function, how it works
and the techniques involved.
– Ensure that the product can be stopped immediately
in the event of an emergency.
– Improper use may cause severe injuries.
– In the event of an accident or a fault during opera-
tion, switch the product off immediately.
Treat injuries properly or consult a doctor.
Who is not permitted to use the product:
• Children and other people who do are not familiar with
the usage instructions (local stipulations may specify a
minimum age for users).
• People under the influence of alcohol, drugs and med-
ication, as well as those who are tired or ill.
7.1 Safety instructions for magazine
attachments
Read all safety instructions and instructions accom-
panying the magazine attachment and the power tool
used. Failure to observe safety information and instruc-
tions can result in electric shock, fire and/or serious inju-
ries.
Save all warnings and instructions for future refer-
ence.
• Before making any adjustments to the power tool,
changing accessories or transporting the power
tool, disconnect the plug from the socket, remove
the battery from the power tool or, if applicable,
set the direction of rotation switch on the power
tool to the middle position. Accidental starting of
power tools is the cause of some accidents.
• Do not reach into the magazine attachment or the
area to be screwed while working. There is a risk of
injury from crushing or sharp-edged screws.
www.scheppach.com
25/30/35/40/45/50/55 mm
6.35 mm
4 mm
Infinitely variable
