ical implants. In order to reduce the
danger of serious or fatal injuries, we
recommend that individuals who wear
medical implants should consult their
doctor and the manufacturer of the
implant before operating the tool.

Preparation

WARNING! Risk of injury due to
unintentional start-up. Only insert
the battery into the device once the
device is fully prepared for use.

Control elements

Familiarise yourself with the operating
elements before using the device for
the first time.
• Direction of rotation switch (15)
(Fig. A)
NOTICE! Only operate the direction
of rotation switch when the tool
has stopped!
The arrow on the direction switch
(15) indicates the working direc-
tion.
• Screw in screw, drill
• Centre Switch lock
• Unscrew screw
• Torque adjustment ring (3)
Setting of the maximum torque
for screwing at which the slipping
clutch is disengaged.
NOTICE! Only operate the torque
adjustment ring when the device is
at a standstill!
• 1 lowest torque
• 25 highest torque
To be safe, start with a low
torque when screwing. Increase
torque ac-cording to require-
ment.
• drilling without torque limit
30
• Gear selector switch (4)
NOTICE! Only operate the gear se-
lector switch when the tool has
stopped.
• 1 Screws
• 2 Drill bits
• On/Off switch (14)
• Switching on: Press
• Control the speed progressively:
The further you press the on/off
switch, the higher the speed.
• Switching off: Release
Attaching and removing the
attachment tool
Notes
• Chuck capacity: 1,5-13 mm
• The direction of rotation is en-
graved in the keyless chuck (2).
• There are magnets (5) on the right
and left of the motor head to hold
frequently used screw bits.
Attaching the attachment tool
(Fig. C)
1. Open the drill chuck: RELEASE➞
2. Push the attachment tool as far as
possible into the drill chuck open-
ing (1).
3. Clamp the attachment tool: ⬅GRIP
Removing the attachment tool
(Fig. C)
1. Open the drill chuck: RELEASE➞
2. CAUTION! Risk of burn injury!
Attachment tools – especially drills
– can become very hot. Wear pro-
tective gloves whenever appropri-
ate.
Remove the attachment tool.
