Read installation and operating instructions in their
entirety before installing the fitting!
Installation, initial operation, operation and
maintenance must only be carried out by qualified
tradesmen!
The installation and operating instructions, as well
as other valid documents must remain with the
user of the system!
Content
1 General information ........................................... 7
2 Safety notes........................................................8
3 Transport, storage and packaging .................... 8
4 Technical data.....................................................8
5 Function..............................................................9
6 Installation ......................................................... 9
7 Accessories ..................................................... 11
8 Maintenance .................................................... 11
9 Warranty .......................................................... 11
10 Charts ............................................................. 12
Illustr. 1 Fitting "Multiblock T", straight pattern
G 3 ⁄ collar nut x G 3 ⁄ male thread
4 4
Illustr. 2 Fitting "Multiblock T", angle pattern
G 3 ⁄ collar nut x G 3 ⁄ male thread
4 4
For an overview of our global presence visit
www.oventrop.com.
Fitting "Multiblock T" for two pipe operation
Installation and operating instructions for the specialised installer
Illustr. 3 Design cover, straight pattern
Illustr. 4 Design cover, angle pattern

1 General information

1.1 Information
operating instructions
These installation and operating instructions serve
the installer to install the fitting professionally and to
put it into operation.
Other valid documents - manuals of all system
components as well as valid technical rules - must
be observed.
1.2 Keeping of documents
These installation and operating instructions should
be kept by the user of the system.
1.3 Copyright
The installation and operating instructions are
copyrighted.
1.4 Symbol explanation
Safety guidelines are displayed by symbols. These
guidelines are to be observed to avoid accidents,
damage to property and malfunctions.
Subject to technical modification without notice.
118401381
Valves, controls + systems
regarding installation
01/2017
and
7
