1 Handle
2 Rotary knob
3 Handle
4 Battery holder
5 LED work light
6 On/Off switch
7 Locking lever
8 Release
9 Cartridge sleeve
10 Push rod
11 Battery
12 Battery release
13 Charger

Description of functions

The push rod inside the cartridge pushes the
product out of the nozzle. The appliance has
a 6-stage adjustable feed rate.
Please refer to the descriptions below for in-
formation on how the operating elements
work.

Technical data

Cordless Caulking Gun ....... PKPA 20-Li A2
Rated voltage U ..................................20 V ⎓
No-load rotation speed n
Feed rate ...................................... 0-19 mm/s
Pressure force .................................... 5000 N
Sound pressure level (L
..........................................69.8 dB; K
Sound power level (L
WA
Vibration (a ) ........... =0.485 m/s²; K=1.5 m/s²
h
Weight (without battery) .....................≈1.6 kg
Temperature ................................. max. 50 °C
–Charging .......................................... 4-40 °C
–Storage ............................................ 4-50 °C
–Operation ....................................... 15-25 °C
Product with battery Smart PAPS 204 A1/
Smart PAPS 208 A1/Smart PAPS 2012 A1:
frequency band .................2400–2483.5 MHz
transmitted power ........................... ≤20 dBm
Notes on noise and vibration values
Levels of noise and vibration were determ-
ined according to the standards and regula-
tions in the declaration of conformity.
−1
.........23000 min
0
)
pA
=3 dB
PA
) 77.8 dB; K =3 dB
WA
GB
CAUTION! Hearing damage! Wear ear
protection.
The specified total vibration values and the
stated noise emission values have been
measured according to a standardised test
method and can be used to compare one
power tool with another. The specified total
vibration values and the stated specified
noise emission values can also be used for a
provisional assessment of the load.
WARNING! The vibration and noise emis-
sions may deviate from the specified value
during actual use of the power tool, depend-
ing on how the power tool is being used and,
in particular, what kind of material is being
worked on. Safety measures for protection
of the operator are to be determined that are
based on an estimate of the vibration load
under the real operating conditions. All parts
of the operating cycle have to be considered
while doing so – for example, times when the
power tool is switched off and times when it
is switched on but running without any load.
X 20 V TEAM
The device is part of the X 20 V TEAM
series and can be operated with batteries
of the X 20 V TEAM series. Batteries of the
X 20 V TEAM series may only be charged
using chargers of the X 20 V TEAM series.
We recommend that you operate this ap-
pliance with the following batteries only:
PAP 20 B1, PAP 20 B3, Smart PAPS 204 A1,
Smart PAPS 208 A1, Smart PAPS 2012 A1
We recommend charging these bat-
teries with the following chargers:
PLG 20 A3, PLG 20 A4, PLG 20 C1,
PLG 20 C2, PLG 20 C3, PLG 201 A1,
PDSLG 20 A1, PDSLG 20 B1, PDSLG 20 B2,
Smart PLGS 2012 A1
Rechargeable battery and charger technical
data: See separate manual.

Safety information

This section deals with the basic safety in-
structions for using the device.
WARNING! Injury and property damage
due to improper handling of battery. Observe
the safety information and notes on charging
and proper use as shown in the instruction
manual for your battery and charger from the
series X 20 V TEAM. A detailed description
MT IE NI
