6.2 Accessories
7. Pulling and lifting in different positions
The following applications may only be carried out after t h e RsqTec TURTLE straps have been fully fitted (see
chapter 6).
The anchorage point must be above the RsqTec TURTLE for all positions and guarantee a minimum load-
bearing capacity of 10 kN.
Horizontal lifting of the person with the RsqTec TURTLE transform:
(i) 2x suspension loops (straps with round ring)
Remove the suspension loops (i) from their side pocket and attach them to the lanyard of the hoist.
Lift the injured person using a suitable lifting device, constantly checking the horizontal position of the person and
correcting it if necessary by changing the position of the person.
Mittelmann Sicherheitstechnik GmbH & Co. KG - Bessemerstrasse 25 - DE-42551 Velbert
Phone : +49 (0)2051 / 91219-00 - Fax : +49 (0)2051 / 91219-19 - Email : info@mittelmann.com
Accessories
- 11 -
Description
The RsqTec TURTLE transform can be
sealed in a transparent vacuum bag and
packed in a transport bag.
The neck support cushion is designed to
relieve tension in the injured person and is
attached to the head area of the rescue
stretcher using the red Velcro material.
