6. Instructions for putting on the RsqTec TURTLE
Before starting, open all buckles, unfold the cover and place the straps to the sides. Place the injured person
with their back on the RsqTec TURTLE transform so that the top of their head is approx. 5 cm away from the
upper edge of the protective tray. Then carry out the following step-by-step instructions for correct belt
application (note: without leg support).
Insert the long side of the leg loops (red (g) or green (h)) from the outside under the
respective thigh. Place around the leg at the crotch and connect with the corresponding
buckles. You must hear and feel the buckles click into place. Pull the straps tight (not
Guide the shoulder belt (e) over the head from above and place it on the person's chest.
Connect the buckles of the shoulder strap in front of the chest to the side parts of the chest
strap (f). Pull the straps tight (not constricting). Allow full freedom of movement of the
Mittelmann Sicherheitstechnik GmbH & Co. KG - Bessemerstrasse 25 - DE-42551 Velbert
Phone : +49 (0)2051 / 91219-00 - Fax : +49 (0)2051 / 91219-19 - Email : info@mittelmann.com
Illustration and description
constricting) without changing the position of the person.
chest for breathing must be guaranteed.
- 6 -
transform harness
