The system is now ready to be applied to the injured person.
Figure left: closed state Figure right: open state
First apply the straps as described in chapter 6. Then secure the leg support to the injured
person's legs from left to right according to this series of pictures. Ensure that the connecting
loop (l from chapter 5.1) is passed between the legs and out of the gap between the fabric
wrappings in order to connect it to the suspension loops (i from chapter 5.1).
The RsqTec TURTLE transform is now ready for use.
