6.1 Instructions for using the leg support:
Illustration and description
The leg support is an integral part of the RsqTec TURTLE transform and is located behind the
back plate. To use the leg support, it must be pulled out and adjusted.
To do this, first undo the Velcro strap with the lettering "OPEN TO USE LEG SUPPORT".
Then pull out the legrest using the red loop.
.
Pull out the leg support and position it so that the orange sticker is at the same height as the
orange webbing. Then attach the black Velcro strap to the Velcro material on the back plate.
Tighten the narrow red and green straps evenly using the adjustable buckles.
