ESQUEMA DEL SISTEMA BOSCH
A
C
Pa r t s & c o m p o n e n t s
LETTER PART DESCRIPTION
A Mini Remote
System Controller
1000mm HMI cable
B
Adaptor for BRC3100
Screw for adaptor
C Rim Magnet/ sleeve (Speed Sensor)
Spider,bash ring & Chainring (Ride Builds)
D Spider, bash ring & Chainring (Pro Builds)
Spider, Bashring & Chainring (Team Builds)
Crank Arms (Ride Builds)
E
Crank Arms (Pro Builds)
Crank Arms (Team Builds)
compactTube 400 Battery (US, CAN, JP, KOR)
F
compactTube 400 Battery (EU28, CH, NO, AUS, NZ)
Battery Charger 4A110V/Cable (US)
G
Battery Charger 4A 230V/Cable(EU)
Battery Charger 4A 230V/Cable(AUS)
Battery Charger 4A 230V/Cable(UK)
H Front Drive unit mounting screw (m8x1x82.3 Long)
Performance line sx drive unit
I
J Drive unit mounting nuts (m8x1)
K rear drive unit mounting screw (m8x1x68.7 Short)
L Performance line sx drive unit logo bezel
M insert sleeve (replace each install)
N o-ring for lockring
O drive unit lockring
- Powermore 250 Kits (Available from Pivot)
P M5x8 Bracket Fastening Screws
q Bracket for PowerMore
r bracket for powermore
s Powermore cable 150mm/250mm
Not Pictured PART DESCRIPTION
- battery adapter 2 (2 PLUG IN LOCATION FOR BATTERY CABLE)
- battery bracket for battery connector
- battery bracket w/o battery connector
- BATTERY bracket mounting screws
- BATTERY CABLE 350MM
Charging Socket & Cable 100mm
CHARGING SOCKET O-RING 24X2
pivotcycles.com
E
D
PART NAME
EB13.100.01E
EB13.100.000
EB12.120.007
EB13.200.0AE
EB13.200.0AF
EB11.200.015/ EB11.200.02S
EP08A-BHV04-DG-C56 /BG50/ 00.6218.034.003
EP08A-BHV04-DG-C56 /BG50/ 00.6218.034.003
EP08A-BHV04-DG-C56 /BG50/ 00.6218.034.003
EC-1ISIS-160A
EC-1ISIS-160A
EC-1ISIS-160CM
EB12.100.043
EB12.100.048
EB12.110.000/ 1270.020.343
EB12.110.001/ 1270.020.330
EB12.110.001/ 1270.020.344
EB12.110.001/ 1270.020.331
EB11.200.0NA
EB11.100.00Y
EB11.200.03C
EB11.200.0N9
EB11.200.09C
EB11.200.0GK
1270.016.119
EB11.200.0JH
Bosch Range Extender 150MM / Bosch Range extender 250mm
FP-SCW-BTN-FLG-M5*0.80*8MM
EB12.110.01A
eb12.110.01a
EB12.120.036/eb12.120.08j
PART NAME
EB12.100.015
EB12.100.03s
EB12.100.03t
EB12.100.03u
EB12.120.00S
EB12.120.048
EB12.120.019
B
I
H
F
M
L
K
T O R Q U E *
G
30 Nm (22 lb·ft) g/l
30 Nm (22 lb·ft) g/l
35 Nm (27 lb·ft)
3 N m ( 2 6 in · l b )
2 Nm (18 in-lb) Y
J
O
N
Q
P
R
S
*Range extender & parts sold separately
