3. FEATURES

Radar shown in figure 1. The main features are:
LED indicators:
Two LED indicators on the front of the radar.
The red LED - DL2 stays on when the power is on.
The green LED - DL1 stays on when obstacles are detected and turns off when there
are no obstacles in the detection area.
Detection area configuration:
By default, the radar detection area in the safety anti-collision mode is 3m in the front
and 0.5m on the left and right.
By default, the radar detection area in the trigger mode is 1.9m in the front and 0.5m
on the left and right.
Different detection areas can be configured via APP.

Parameters configuration:

The configuration of the detection area can be saved automatically, and the latest
parameters will be loaded after the radar is turned off and restarted.
Firmware upgrade:
The firmware can be updated online via the app, without disassembling the radar, and
the new firmware will be effective by simply restarting the radar.
Stable performance:
With microwave technology, it works perfectly even in difficult environments, such as
different light conditions, rain, fog, snow and dust.
32,2
73,6
17,2
fig. 1
