Instructions for installation

1.7. Parts list

No. of
Name
items
Base frame
2 Base frame (impregnated)
2 Base frame (impregnated)
W1: Front side with door
1 Block plank with hole for cable
13 Block plank
1 Block plank above the door
1 Block plank upper triangle
W2: Side wall
14 Block plank
1 Block plank with holes for exhaust air
1 Block plank with holes for ventilation
W3: Rear wall
15 Block plank
1 Block plank upper triangle
W4: Side wall with window
1 Block plank with holes for air supply
12 Block plank with hole for cable
13 Block plank
1 Block plank above the window
3 Block plank with hole for cable
1 Block plank with holes for ventilation
Floor
6 Base frame (impregnated) with cut-out
1 Base frame (impregnated) with cut-out
6 Base frame (impregnated)
20 Floor boards
2 Skirting board
1 Skirting board
1 Skirting board
1 Skirting board
1 Skirting board
p. 7/16
Dimensions
mm
1910x146x40
1990x146x40
1085x146x40
1085x146x40
1910x146x40
1910x397x40
1990x146x40
1990x146x40
1990x131x40
1910x146x40
1910x397x40
1345x146x40
1345x146x40
135x146x40
1990x146x40
1990x146x40
1990x131x40
1905x100x40
1905x100x40
272x100x40
1900x95x19
1910x25x20
1055x25x20
780x25x20
1290x25x20
70x25x20
