Sentiotec SCALA Medium Montageanleitung Seite 8

Instructions for installation
No. of
Name
items
Corner covers
8 Corner cover
2 Corner cover
2 Corner cover 82°
2 Corner cover
2 Corner cover 82°
Inner roof
1 Roof panel
1 Roof panel
1 Roof support strip 82°
1 Roof support slat
1 Roof support strip 2x82° left
1 Roof support strip 2x82° right
Outer roof
4 Roof rafters
4 Roof rafters
3 Roof rafters
2 Wind batten support strips 82°
2 Wind batten support strips 82°
1 Wind batten support strips 82°
1 Wind batten support strips 82°
19 Roof tongue and groove planks
19 Roof tongue and groove planks
18 Roof tongue and groove planks
18 Roof tongue and groove planks
2 Wind battens 82° sideways bottom
2 Wind battens 82° sideways top
4 Wind battens
Door
1 Outer door incl. door frame
2 Door panel inside
1 Door panel inside
1 Door panel inside
p. 8/16
Dimensions
mm
1000x80x20
1630x80x20
1630x80x20
1360x80x20
1360x80x20
1890x955x55
1890x955x55
1910x40x40
1910x40x40
1847x40x40
1847x40x40
2060x130x40
1495x130x40
767x128x40
1719x128x40
1828x130x40
1390x40x40
1965x40x40
1024x95x19
2096x95x19
1586x95x19
1534x95x19
1607x150x20
1534x150x20
1718x150x20
1955x890x70
1950x55x20
780x55x20
800x55x20
