Parts List - Sentiotec SCALA Large Montageanleitung

Instructions for installation

1.7. Parts list

No. of
Name
items
Base frame
2 Base frame (impregnated)
2 Base frame (impregnated)
1 Base frame (impregnated), middle wall
2 Base frame (impregnated)
W1: Front side with window and door
1 Block plank with holes for air supply
9 Block plank
14 Block plank
3 Block plank
3 Block plank
2 Block plank
2 Block plank
1 Block plank below the window
1 Block plank above the window
1 Block plank above the door
1 Block plank with holes for ventilation
1 Block plank with holes for ventilation
W2: Side wall
15 Block plank
1 Block plank upper triangle
W3: Rear wall
1 Block plank with holes for exhaust air
14 Block plank
15 Block plank
1 Block plank with holes for ventilation
1 Block plank with holes for ventilation
W4: Side wall
15 Block plank
1 Block plank upper triangle
W5: Medium wall
14 Block plank
13 Block plank with hole for cable
1 Block plank with hole for cable
1 Block plank above the door
1 Block plank upper triangle
p. 7/14
Dimensions
mm
2080x40x146
1990x40x146
1910x40x146
1910x40x146
2160x146x40
2160x146x40
1040x146x40
118x146x40
287x146x40
1990x146x40
2080x146x40
2160x146x40
1990x146x40
2080x146x40
1990x131x40
2080x131x40
1910x146x40
1910x397x40
1990x146x40
1990x146x40
2080x146x40
1990x131x40
2080x131x40
1910x146x40
1910x397x40
110x146x40
980x146x40
980x146x40
1910x146x40
1910x397x40
