Sentiotec SCALA Medium Montageanleitung Seite 9

Instructions for installation
No. of
items Name
Window
1 Insulating safety glass
2 Window frame
Interior fittings
1 Bench
1 Bench
1 Bench
2 Backrests
2 Bench support slats
3 Bench support slats
2 Heater protection grille
1 Heater protection grille
1 Heater protection grille
1 Heater protection guard (strut)
Terrace
5 Base frame (impregnated)
3 Base frame (impregnated)
3 Base frame (impregnated)
10 Terrace floorboards
16 Terrace floorboards
10 Terrace floorboards
2 Cover strip
1 Cover strip
1 Screen element
1 Screen element
1 Screen element
2 Roof supports
1 Roof supports
p. 9/16
Dimensions
mm
1587x506x16
1805x560x32
1900x600x88
1900x500x88
1305x600x88
1800x220x48
1045x88x28
595x88x28
1000x88x28
490x70x28
675x70x28
575x88x28
1210x95x40
2000x95x40
1375x95x40
2010x120x25
825x120x25
805x120x25
1408x95x25
825x95x25
1970x1125x60
1970x800x60
1067x700x60
2550x70x70
2180x70x70
EN
