c) The blade is very sharp. This poses a risk of injury. Do not touch the blade.
2

Technical Data

Code ............................................................. 1500004349
For pipe dimensions (mm) ........................... 250-800
For pipe dimensions IPS .............................. 10-30
For pipe dimensions DIPS ........................... 10-24
Suitable for pipes made of ........................... PE, PE-HD, PE-X, PP
Peeling depth (mm) ...................................... 0,3 (0,25 to 0,35)
Dimensions, weights and packaging:
Product dimensions L×W×H (mm) ............... Depending on pipe dimension×100×85
Product weight (kg) ...................................... 6,1
Packaging dimensions L×W×H (mm) ........... 590×390×425
Packaging material ....................................... Plastic
Packaging type ............................................. Suitcase
Packaging weight (kg) .................................. 3,5
Transport weight (kg) ................................... 9,6
Scope of delivery: Instruction manual, ROSCRAPER 800, 1 x clamping and peeling unit, 4 x
roller carriage with intermediate piece 55 mm, 4 x roller carriage with intermediate piece 85 mm,
1 x spare blade, Allen key 2 mm, ROCASE 6427 with foam inserts.
3

Function of the Unit

3.1 Overview
Pos. Description
1 Roller wagon with link piece 55 mm
2 Roller wagon with link piece 85 mm
3 Biasing and peeling unit
4 Feeding wheel, large
5 Peeler blade, large
6 Running wheel
7 Ratchet strap 25 mm incl. handle
8 Adjustment knob M6
- Hex key screwdriver
3.2

Composition of the Chain Peeler

Danger of cutting injuries by scraper blade! The blade is very sharp! Handling the spare
blades involves a high risk of injury. Always wear cut-proof gloves as soon as you
handle the peeling blades!
Depending on the dimension of the pipe a different number of roller wagons and link pieces
must to be used. A complete Chain Peeler consists of a biasing and peeling unit and, depending
on the ordered version (plus optional extension), a different number of roller wagons with link
pieces. The table below gives an overview of the composition for different pipe diameters.
Code
1500004520
1500004521
1500004522
1500004523
1500004524
1500004525
1500004526
1500004527
321211
