Technical Specifications

Conformity
Standard
Installing the product
Operating temperatures
Storage temperatures
Power
Gateway consumption
Network Frequency
Safety class
Environmental class
Mass
Protection rating
Max. radio frequency power
transmitted
Input voltage
Input frequency
Outlet
Safety class
Operating temperatures
Storage temperatures
Standard
REMOCON NET B
LVD: 2014/35/EU
EMC: 2014/30/EU
RED: 2014/53/EU
ROHS: 2011/65/EU (2015/863/EU)
LVD: EN 62368; EN 62311
EMC: ETSI EN 301 489-1; ETSI EN301 489-17
RED: ETSI EN 300 328
ROHS: EN63000
Mounted on the wall
or on any smooth surface
-10°C +60°C
-20°C +70°C
0-12Vdc
Max 40 mA - Max 0.7 W
2,4 GHz (5 GHz is not supported)
III
3
0.1 kg
IP 20
<20 dBm
Transformer
100 to 240 Vac
50 to 60 Hz
500mA @ 12.0 Vdc
II
0°C to 40°C
-20°C to 50°C
LVD: EN60950
EMC: EN55022
44
WARNING!
Only use the transformer in
combination with a REMOCON NET B
gateway
IMPORTANT!
REMOCON NET B is compatible
with the following regulation
modules:
· LMU 74
· LMS 14
· RVS 13 (LOGON B G1Z1)
· RVS 43 (LOGON B G2Z1)
· RVS 46 (LOGON B WZ1)
· RVS 51 (LOGON B WP)
· RVS 61 (LOGON B WP)
· RVS 63 (LOGON B G2Z2)
