Commissioning
There are four fixing holes for
◆
mounting the decod er.
The use of spacer sleeves with a height of 5
◆
millimeters is recommended to avoid
mechanical stress caused by unevenness.
The surface of the installation location and
◆
other materials in contact with the decoder
should be made of non-conductive material.
The installation location should be protected from
◆
accidental contact by persons or objects.
Installation
Dimensions
Width 90mm
◆
Depth 50mm
◆
Height approx. 25mm
◆
Fastening
4 M3 fixing holes
◆
Inner diameter 3.5mm
◆
Connections
Tool-free plug-in connections
◆
Maximum cross-section 1mm
◆
Field of application
The decoders are designed for a storage and
◆
continuous operating temperature range of 0-
50° Celsius.
Avoid large temperature fluctuations.
◆
