Commissioning

The decoder is intended for mounting in a
◆
Märklin or Trix C-track turnout and has 3
mounting holes for this.
Carefully press
◆
mounting pins provided in the inner bed of
the turnout.
The side fitted with components always
◆
points towards the switch.
The surface of the installation site and other
◆
materials in contact with the decoder should
be made of non-conductive material.
Installatio
n
the decoder onto
Field of application
The decoders are designed for a storage
◆
and continuous operating temperature
the
range of 0-50° Celsius.
Avoid large temperature fluctuations.
◆
