All assembly, electrical installation and maintenance work is to be carried out by authorised, qualifi ed technicians
!
who have carefully read all the installation and maintenance instructions.
Components and installation
76752 CONTROL CONNECT All IN ONE
565 mm
FLOW
OK
Control Connect
All in One
Control Connect
All in One
Open
Wall mounting
Screws and wall
plugs not supplied
Wall plug: 7 x 35 mm
Screw: 5 x 35 mm
131 mm
For further information on installation and wiring,
see complete manual.
Connection
1
6
FLOW
UV
COVER
Cl EXT
-
+
-
+
5
AUX 1
pH PUMP
AUX 2
11
N
L
10
Power cable
not supplied
10
11
L
N
131 mm
CAUTION: Always install
the equipment on a fi rm
surface in a dry, ventilated
location. We recommend
installing the equipment
where it will be protected
from the weather. Avoid
creating corrosive atmos-
pheres.
Control Connect ALL IN ONE
F10E
2
PH
3
8
ORP
4
7
9
VSP
FLOW
1
FLOW
COVER
Cl EXT
-
+
Accessories
pH ORP
pH
ORP
pH
Optional accessories
77420 VSP DRIVER KIT
C.C. ALL IN ONE
1
8
pH
ORP
5
FLOW
12
pH
ORP
6
13
IN 4
IN 3
IN 2
IN 1
2
Interlocks
4 X INPUT FREE POTENTIAL
(Loop 0V)
3 X Output 230 Vac
UV
-
+
5
6
AUX 1
pH PUMP
AUX 2
230 Vac
(< 1.5 A)
ORP
pH
230 Vac
230 Vac
(< 0.5 A)
(< 0.5 A)
pH/ORP
sensors
pH/ORP
peristaltic
ORP
Optional accessories
77584
LEVEL SENSOR
AND SUCTION KIT
(1 unit)
VSP
1) Temperature sensor
2) Interlocks
3) MODBUS
4) R1–R4 outputs
5) Inductive fl ow sensor
6) pH/ORP pumps
7) Level sensor
8) pH/ORP sensor
9) VSP driver
10) 230 Vac feed
11) R1–R4 relays
12) Flow control
13) Panel inlet (fi lter)
14) Panel outlet
14
MODBUS
OUT 4
OUT 3
OUT 2
- C +
3
4
4 X POTENTIAL-FREE OUTPUTS
(Loop max 24 V 1A AC-DC)
pH Level
Cl Level
HEAT
7
LEVEL SENSOR
AND SUCTION
(Optional)
pump
OUT 1
LED
