All assembly, electrical installation and maintenance work is to be carried out by authorised, qualifi ed technicians
!
who have carefully read all the installation and maintenance instructions.
Components and installation
Control unit
For further information on installation and wiring, see complete
manual.
Connection
Control Connect
pH/ORP
6
8
9
7
10
AUX 2
AUX 1
FLOW SWITCH
TEMP (ºC)
1) pH sensor
2) ORP sensor
General installation diagram
Mount: 8 x 50 mm
Screw: 5 x 50 mm
CAUTION: Always install upright on a
rigid surface in a dry, ventilated area.
We recommend installing the equipment
where it will be protected from the weath-
er. Avoid creating corrosive atmospheres.
6
7
4
2
1
AUX 1
AUX 2
123
VSP
INDUCTIVE
SENSOR
ORP
pH
3) PPM sensor
5) 230 V
4) VSP
6) Temperature
Fluidra Pool
Electrical control panel
Control Connect
pH/ORP
Control Connect
pH/ORP_panel
Control Connect
pH/PPM_panel
VSP driver
Control Connect
pH/ORP_panel
4
7
1
4
10
2
123
VSP
TEMP (ºC)
pH
ORP
7) Flow switch/inductive sensor
8) pH injection
Control
230 V
unit
always on
ClmV
720
720
Elite Connect
BLUE
pH
ORP
Optional accessories
Peristaltic pump
Control Connect
pH/PPM_panel
5
6
7
10
AUX 1
AUX 2
TEMP (ºC)
INDUCTIVE
SENSOR
9) Cl injection
10) 230 Vac feed
Dosing
pump
pH
Cl
Outlet
N.B.: This diagram is a general
representation of an installation that
Inlet
includes all available options, so it
might vary, depending on the specifi c
model.
4
7
1
4
3
123
VSP
pH
PPM
