Base Support (For wall mounting only)
Base support
M5*8 Phillips
countersunk head
screw
Items
Base supports
Transverse plate
Expansion screws
M5*20 Phillips countersunk head screws
M5*8 Phillips countersunk head screws
Series Box (For two towers only)
Series Box
Base
Expansion screw
Cover
Items
Series box
Base
Angle brackets
Adjustable brackets
Expansion bolts
Transverse plate
Angle bracket
Adjustable bracket
Power cable (black)
Power cable (red)
Document
Expansion screw
Quantity
2 pcs
1 pc
6 pcs
6 pcs
4 pcs
Expansion bolt
Tapping
screw
Communication cable
Heater cable
Quantity
1 pc
1 pc
4 pcs
4 pcs
6 pcs
M5*20 Phillips
countersunk head
screw
M5*14 Phillips cheese
head screw
Grounding cable
