Do not use your hands or feet to remove clippings
in or on the mower housing, but instead use suitable
tools such as a brush or a hand broom.
In order to ensure that the majority of grass clippings
are picked up, the inside of both the grass basket (16)
and especially the air grill must be cleaned after each
use. Reattach the grass basket (16) only when the
engine is switched off and the blade is stopped. Using
one hand, lift up the chute flap (15), while grabbing
onto the basket handle with the other. Hang in the
basket from the top. Fig. 9
After mowing
• Allow the engine to cool before you put the lawn
mower in an enclosed area.
Remove grass, foliage, grease and oil before stor-
ing the mower. Do not place any objects on top of
the mower.
• Check all the screws and nuts once more before
you start to use the lawn mower again. Tighten any
loose screws.
• Also be sure to empty the grass basket (16).
• Pull the spark plug boot to prevent unauthorized use.
• Ensure that you do not park the mower next to any
source of danger. Petrol fumes can lead to explo-
sions.
• Only original parts or parts approved by the man-
ufacturer may be used for repairs (see address on
the warranty certificate).
• If the lawn mower is not going to be used for an ex-
tended period, empty the petrol tank using a petrol
suction pump.
• Oil and maintain the machine.
10. Cleaning
The lawn mower should be thoroughly cleaned after
every use, especially the underneath and the blade
mount. To remove the gras, tip the lawn mower onto
its left side (the opposite side to the oil filling socket)
or clean the mower with water as descript below:
• Remove the mulch unit / gras box.
• Fit the hose connection to the mower and turn the
tap on. (Fig. 23)
• Start the mower and switch off again after about 30
seconds. The rotating blade bar throws the water
onto the bottom of the mower and thus cleans it.
• Turn off the tap and remove the hose connection .
• Clean the top with a cloth (do not use any sharp
objects).
Note! Before you tip the lawn mower onto its side,
completely empty the fuel tank using a petrol suc-
tion pump. The lawn mower must never be tilted by
more than 90 degrees. Dirt and grass is easiest to
remove immediately after you have finished mowing
the grass. Dried on grass and dirt can result in poorer
mowing performance.
Check that the grass chute is free of any residual grass.
Remove any such residue. Never clean the lawn mow-
er with a water jet or high-pressure cleaner. The en-
gine must remain dry. Do not use aggressive cleaning
agents such as cold cleaner or petroleum ether.
11. Transport
• Empty the petrol tank.
• Always let the engine run until it has used up the
remainder of petrol in the tank.
• Empty the engine oil from the warm engine.
• Remove the spark plug boot from the spark plug.
• Clean the cooling fins of the cylinder and the housing.
• Remove the start tension cable (17) from the hook.
Loosen the quick-release lever (5) and fold the up-
per push bar down. Make sure the cables are not
bent during this process.
• Wedge a few layers of corrugated cardboard be-
tween the upper and lower push bars and the en-
gine in order to prevent any chafing.
12. Storage
Store the device and its accessories in a dark, dry
and frost-free place that is inaccessible to children.
The optimum storage temperature lies between 5 and
30 ˚C.
Store the power tool in its original packaging.
Cover the power tool to protect it from dust or mois-
ture. Store the operating manual with the power tool.
• Never store the mower (with petrol in the tank) in-
side a building in which petrol fumes could come
into contact with open flames or sparks.
• Allow the motor to cool before you put the lawn
mower in an enclosed area.
• In order to avoid fire hazards, keep the engine, ex-
haust and the area around the fuel tank free from
grass, leaves and leaking grease (oil).
Preparing the mower for long-term storage
Caution: Do not empty the petrol tank in enclosed
areas, near fire or when smoking. Petrol fumes can
cause explosions and fire.
• Empty the petrol tank with a petrol suction pump.
• Start the engine and let it run until any remaining
petrol has been used up.
• Change the oil at the end of every season. To do
so, remove the used engine oil from a warm engine
and refill with fresh oil.
• Remove the spark plug from the cylinder head.
• Fill the cylinder with approx. 20 ml of oil from an
oil can.
• Slowly pull back the starter handle, which will bathe
the cylinder wall with oil. Screw the spark plug back in.
• Clean the cooling fins of the cylinder and the housing.
