RELAY ACTIVATION LOGIC (12V)

The relay activation logic depends on the working settings of the unit. No additional
configuration is required in the Aidoo device.
ES

Advanced settings

PRIOR MANUFACTURER CONFIGURATION

The unit must be configured to work with a circuit in room temperature mode in order to
guarantee the correct operation of the Aidoo device. The following configurations must be
made from the manufacturer's wired controller:
• Select the unit's working settings:
Settings > Installer level > Installation configuration > Circuit 1 > Room temp. mod.
• Select the operation mode of the water circuit:
Settings > Installer level > Installation configuration > Circuit 1 > Circuit type: Heating
The following optional configurations can also be made:
• If the unit has a cooling function and you wish to use it:
Settings > Installer level > Installation configuration > Circuit 1 > Cooling possible: Yes
• If the unit has a DHW storage tank and you wish to use it:
Settings > Installer level > Installation configuration > DHW > Cylinder: Active
• If you want to set an outdoor temperature limit to turn the unit off automatically when it is
working in heating mode:
Settings > Installer level > Installation configuration > Circuit 1 > OT switch-off threshold:
(Enter the desired value)
16
Aerotermia modo temp. ambiente
Estado
Circuito 1 OFF
Circuito 1 ON
Circuito 1 en demanda
ACS ON
ACS OFF
Relé
OFF
OFF
ON
OFF
OFF
