RELAY ACTIVATION LOGIC (12V)
The relay activation logic depends on whether the air to water unit is configured to work with
supply water temperature or room temperature. If there is more than one zone, they must all
have the same working settings. No additional configuration is required in the Aidoo.
EN
Air to Water supply temperature mode
Circuit status
Circuit 1 y Circuit 2 OFF
Circuit 1 and/or Circuit 2 ON
Circuit 1 and/or Circuit 2 on
demand
DHW ON
DHW OFF
Advanced settings
PRIOR MANUFACTURER CONFIGURATION
The unit must be configured from the installer menu in order to function correctly:
•
Set the indoor unit address to address 1:
1.
Go to menu "17. HMI ADDRESS SET".
2. Set the parameters to the following values:
17.1 HMI SET = MASTER
17.2 HMI ADDRESS FOR BMS = 1
•
Set the unit to the desired mode:
a.
Room temperature mode:
1.
Go to menu "5. TEMP. TYPE
SETTING".
2.
Set the parameters to the following
values:
5.1 WATER FLOW TEMP = NON
5.2 ROOM TEMP = YES
5.3 DOUBLE ZONE = NON
3. Go to menu "6. ROOM
THERMOSTAT".
4. Set the parameters to the following
values:
6.1 ROOM THERMOSTAT = NON
Note: changes must be saved before exiting the menu.
12
Air to Water room temperature mode
Relay
OFF Circuit 1 y Circuit 2 OFF
ON Circuit 1 and/or Circuit 2 ON
ON Circuit 1 and/or Circuit 2 on
OFF
OFF
b.
Supply temperature mode:
1.
2.
3.
4.
Circuit status
demand
DHW ON
DHW OFF
Go to menu "5. TEMP. TYPE
SETTING".
Set the parameters to the following
values:
5.1 WATER FLOW TEMP = YES
5.2 ROOM TEMP = NON
5.3 DOUBLE ZONE = (NON for 1
circuit, YES for 2 circuits)
Go to menu "6. ROOM
THERMOSTAT".
Set the parameters to the following
values:
6.1 ROOM THERMOSTAT = NON
Relay
OFF
OFF
ON
OFF
OFF
