RELAY ACTIVATION LOGIC (12V)

The relay activation logic depends on whether the air to water unit is configured to work with
supply water temperature or room temperature. If there is more than one zone, they must all
have the same working settings. No additional configuration is required in the Aidoo.
EN
Aerothermal TAI mode
Circuit status
Circuit 1 y Circuit 2 OFF
Circuit 1 and/or Circuit 2 ON
Circuit 1 and/or Circuit 2 on
demand
DHW ON
DHW OFF

Advanced settings

PRIOR MANUFACTURER CONFIGURATION

The unit must be configured as follows in order to function correctly:
•
To select the type of control:
Installer settings > System layout > Standard > Unit control method > C – 07:
0: water supply temperature mode (TAI)
1: external room thermostat mode (external TH) (not permitted)
2: room temperature mode (TH)
•
To configure the DHW heating mode:
Installer settings > System layout > Standard > Unit control method > 6 – 0D: 0 ("Reheat
only")
•
The "Setpoint mode" control configuration parameter must be set to "Fixed" (by default it
usually is).
Important: the selected set-point temperatures of the Daikin controller must not be
changed once configured.
12
Relay
OFF Circuit 1 y Circuit 2 OFF
ON Circuit 1 and/or Circuit 2 ON
ON Circuit 1 and/or Circuit 2 on
OFF
OFF
Aerothermal TH mode
Circuit status
demand
DHW ON
DHW OFF
Relay
OFF
OFF
ON
OFF
OFF
