RELAY ACTIVATION LOGIC (12V)

The relay activation logic depends on whether the air to water unit is configured to work with
supply water temperature or room temperature. If there is more than one zone, they must all
have the same working settings. No additional configuration is required in the Aidoo.
EN
Air to Water supply temperature mode
Circuit status
Circuit 1 y Circuit 2 OFF
Circuit 1 and/or Circuit 2 ON
Circuit 1 and/or Circuit 2 on
demand
DHW ON
DHW OFF

Advanced settings

PRIOR MANUFACTURER CONFIGURATION

The unit must be configured as follows in order to function correctly:
1. Advanced Configuration > Controller Type:
•
Room temperature mode: Unit + Room
•
Supply temperature mode: Unit
2. Select the circuits controlled by the device: (C1), (C2) or (C1 + C2).
3.
Configure the circuits to be used in Heating as "Fix". Indicate whether DHW is available.
4. Configure the circuits to be used in Cooling as "Fix".
5. Configure the "Central Mode" as "Full".
Note: the unit may need to be restarted after performing the configuration.
In Cooling mode, supply temperatures must be set to a maximum of 22°C and a minimum of
5°C: System Configuration > Space Cooling > Circuit 1 > Working limits.
12
Air to Water room temperature mode
Relay
OFF Circuit 1 y Circuit 2 OFF
ON Circuit 1 and/or Circuit 2 ON
ON Circuit 1 and/or Circuit 2 on
OFF
OFF
Circuit status
demand
DHW ON
DHW OFF
Relay
OFF
OFF
ON
OFF
OFF
